Ethernet Network Connection

Another common configuration is to have the PC/laptop connected to the same local area network as the analyzer.

Figure 11 - Ethernet network connection





Figure 12 - Location of Ethernet port for cable connection

NOTE: Some PGA units will have only one Ethernet port. If only one is available, use that one.



To get this configuration working correctly you must set the TCP/IP settings of the analyzer to be compatible with your network.   Your PC should already be configured correctly.

Ask your IT department or network administrator for appropriate IP Address / Net Mask / Gateway settings.
